ATmega162/V

2513E–AVR–09/03

Notes: 1. This command sequence is not required if the seven MSB are correctly set by the previous command sequence (which is

normally the case).

2. Repeat until o = “1”.

3. Set bits to “0” to program the corresponding Fuse, “1” to unprogram the Fuse.

4. Set bits to “0” to program the corresponding lock bit, “1” to leave the Lock bit unchanged.

5. “0” = programmed, “1” = unprogrammed.

6. The bit mapping for Fuses Extended byte is listed in Table 99 on page 231.

7. The bit mapping for Fuses High byte is listed in Table 100 on page 232.

8. The bit mapping for Fuses Low byte is listed in Table 101 on page 232.

9. The bit mapping for Lock Bits byte is listed in Table 97 on page 230.

10. Address bits exceeding PCMSB and EEAMSB (Table 106 and Table 107) are don’t care

Note: a = address high bits

b = address low bits

H = 0 – Low byte, 1 – High Byte

o = data out

i = data in

x = don’t care

8f. Read Fuses and Lock Bits 0111010_00000000

0111110_00000000

0110010_00000000

0110110_00000000

0110111_00000000

xxxxxxx_xxxxxxxx

xxxxxxx_oooooooo

(5)

Fuse ext. byte

Fuse high byte

Fuse low byte

Lock bits

9a. Enter Signature Byte Read 0100011_00001000 xxxxxxx_xxxxxxxx

9b. Load Address Byte 0000011_bbbbbbbb xxxxxxx_xxxxxxxx

9c. Read Signature Byte 0110010_00000000

0110011_00000000

xxxxxxx_xxxxxxxx

xxxxxxx_oooooooo

10a. Enter Calibration Byte Read 0100011_00001000 xxxxxxx_xxxxxxxx

10b. Load Address Byte 0000011_bbbbbbbb xxxxxxx_xxxxxxxx

10c. Read Calibration Byte 0110110_00000000

0110111_00000000

xxxxxxx_xxxxxxxx

xxxxxxx_oooooooo

11a. Load No Operation Command 0100011_00000000

0110011_00000000

xxxxxxx_xxxxxxxx

Table 112. JTAG Programming Instruction Set (Continued)

Instruction TDI sequence TDO sequence Notes
