235

ATmega162/V

2513E–AVR–09/03

Parallel Programming

Enter Programming Mode The following algorithm puts the device in Parallel Programming mode:

1. Apply 4.5 - 5.5V between V

and GND, and wait at least 100 µs.

2. Set RESET

to “0” and toggle XTAL1 at least six times.

3. Set the Prog_enable pins listed in Table 103 on page 234 to “0000” and wait at

least 100 ns.

4. Apply 11.5 - 12.5V to RESET

. Any activity on Prog_enable pins within 100 ns

after +12V has been applied to RESET

, will cause the device to fail entering Pro-

gramming mode.

Considerations for Efficient

Programming

The loaded command and address are retained in the device during programming. For

efficient programming, the following should be considered.

• The command needs only be loaded once when writing or reading multiple memory

locations.

• Skip writing the data value 0xFF, that is the contents of the entire EEPROM (unless

the EESAVE Fuse is programmed) and Flash after a Chip Erase.

• Address high byte needs only be loaded before programming or reading a new 256-

word window in Flash or 256 byte EEPROM. This consideration also applies to

Signature bytes reading.

Table 105. Command Byte Bit Coding

Command Byte Command Executed

1000 0000 Chip Erase

0100 0000 Write Fuse Bits

0010 0000 Write Lock Bits

0001 0000 Write Flash

0001 0001 Write EEPROM

0000 1000 Read Signature Bytes and Calibration byte

0000 0100 Read Fuse and Lock Bits

0000 0010 Read Flash

0000 0011 Read EEPROM

Table 106. No. of Words in a Page and no. of Pages in the Flash

Flash Size Page Size PCWORD No. of Pages PCPAGE PCMSB

8K words (16K bytes) 64 words PC[5:0] 128 PC[12:6] 12

Table 107. No. of Words in a Page and no. of Pages in the EEPROM

EEPROM Size Page Size PCWORD No. of pages PCPAGE EEAMSB

512 bytes 4 bytes EEA[1:0] 128 EEA[8:2] 8
