222

ATmega162/V

2513E–AVR–09/03

Addressing the Flash

During Self-

programming

The Z-pointer is used to address the SPM commands.

Since the Flash is organized in pages (see Table 106 on page 235), the Program

Counter can be treated as having two different sections. One section, consisting of the

least significant bits, is addressing the words within a page, while the most significant

bits are addressing the pages. This is shown in Figure 95. Note that the Page Erase and

Page Write operations are addressed independently. Therefore it is of major importance

that the Boot Loader software addresses the same page in both the Page Erase and

Page Write operation. Once a programming operation is initiated, the address is latched

and the Z-pointer can be used for other operations.

The only SPM operation that does not use the Z-pointer is Setting the Boot Loader Lock

bits. The content of the Z-pointer is ignored and will have no effect on the operation. The

LPM instruction does also use the Z-pointer to store the address. Since this instruction

addresses the Flash byte-by-byte, also the LSB (bit Z0) of the Z-pointer is used.

Figure 95. Addressing the Flash during SPM

(1)

Notes: 1. The different variables used in Figure 95 are listed in Table 96 on page 229.

2. PCPAGE and PCWORD are listed in Table 106 on page 235.

Bit 151413121110 9 8

ZH (R31) Z15 Z14 Z13 Z12 Z11 Z10 Z9 Z8

ZL (R30) Z7Z6Z5Z4Z3Z2Z1Z0

76543210

PROGRAM MEMORY

0115

Z - REGISTER

BIT

ZPAGEMSB

WORD ADDRESS

WITHIN A PAGE

PAGE ADDRESS

WITHIN THE FLASH

ZPCMSB

INSTRUCTION WORD

PAGE

PCWORD[PAGEMSB:0]:

PAGEEND

PAGE

PCWORDPCPAGE

PCMSB

PAGEMSB

PROGRAM

COUNTER
