ATmega162/V

2513E–AVR–09/03

ming of the Flash memory by SPM instruction. Similarly, the general Read/Write Lock

(Lock bit mode 1) does not control reading nor writing by LPM/SPM, if it is attempted.

Note: 1. “1” means unprogrammed, “0” means programmed

Table 90. Boot Lock Bit0 Protection Modes (Application Section)

(1)

BLB0 Mode BLB02 BLB01 Protection

111

No restrictions for SPM or LPM accessing the Application

section.

2 1 0 SPM is not allowed to write to the Application section.

300

SPM is not allowed to write to the Application section, and

LPM executing from the Boot Loader section is not

allowed to read from the Application section. If Interrupt

Vectors are placed in the Boot Loader section, interrupts

are disabled while executing from the Application section.

401

LPM executing from the Boot Loader section is not

allowed to read from the Application section. If Interrupt

Vectors are placed in the Boot Loader section, interrupts

are disabled while executing from the Application section.

Table 91. Boot Lock Bit1 Protection Modes (Boot Loader Section)

(1)

BLB1 Mode BLB12 BLB11 Protection

111

No restrictions for SPM or LPM accessing the Boot Loader

section.

2 1 0 SPM is not allowed to write to the Boot Loader section.

300

SPM is not allowed to write to the Boot Loader section,

and LPM executing from the Application section is not

allowed to read from the Boot Loader section. If Interrupt

Vectors are placed in the Application section, interrupts

are disabled while executing from the Boot Loader section.

401

LPM executing from the Application section is not allowed

to read from the Boot Loader section. If Interrupt Vectors

are placed in the Application section, interrupts are

disabled while executing from the Boot Loader section.
