IDCODE; 0x1 Optional JTAG instruction selecting the 32-bit ID-register as data register. The ID-Regis-
ter consists of a version number, a device number and the manufacturer code chosen
by JEDEC. This is the default instruction after Power-up.
The active states are:
• Capture-DR: Data in the IDCODE Register is sampled into the Boundary-scan
Chain.
• Shift-DR: The IDCODE scan chain is shifted by the TCK input.
SAMPLE_PRELOAD; 0x2 Mandatory JTAG instruction for preloading the output latches and taking a snapshot of
the input/output pins without affecting the system operation. However, the output latches
are not connected to the pins. The Boundary-scan Chain is selected as Data Register.
The active states are:
• Capture-DR: Data on the external pins are sampled into the Boundary-scan Chain.
• Shift-DR: The Boundary-scan Chain is shifted by the TCK input.
• Update-DR: Data from the Boundary-scan chain is applied to the output latches.
However, the output latches are not connected to the pins.
AVR_RESET; 0xC The AVR specific public JTAG instruction for forcing the AVR device into the Reset
mode or releasing the JTAG Reset source. The TAP controller is not reset by this
instruction. The one bit Reset Register is selected as data register. Note that the reset
will be active as long as there is a logic 'one' in the Reset Chain. The output from this
chain is not latched.
The active states are:
• Shift-DR: The Reset Register is shifted by the TCK input.
BYPASS; 0xF Mandatory JTAG instruction selecting the Bypass Register for data register.
The active states are:
• Capture-DR: Loads a logic “0” into the Bypass Register.
• Shift-DR: The Bypass Register cell between TDI and TDO is shifted.
Boundary-scan Related
Register in I/O Memory
MCU Control and Status
Register – MCUCSR
The MCU Control and Status Register contains control bits for general MCU functions,
and provides information on which reset source caused an MCU Reset.
• Bit 7 – JTD: JTAG Interface Disable
When this bit is zero, the JTAG interface is enabled if the JTAGEN Fuse is programmed.
If this bit is one, the JTAG interface is disabled. In order to avoid unintentional disabling
or enabling of the JTAG interface, a timed sequence must be followed when changing
this bit: The application software must write this bit to the desired value twice within four
cycles to change its value.
Bit 76543210
JTD
– SM2 JTRF WDRF BORF EXTRF PORF MCUCSR
Read/Write R/W R/W R R/W R/W R/W R/W R/W
Initial Value 0 0 0 See Bit Description
