SS Pin Functionality

Slave Mode When the SPI is configured as a slave, the Slave Select (SS) pin is always input. When

is held low, the SPI is activated, and MISO becomes an output if configured so by

the user. All other pins are inputs. When SS

is driven high, all pins are inputs, and the

SPI is passive, which means that it will not receive incoming data. Note that the SPI

logic will be reset once the SS

pin is driven high.

The SS

pin is useful for packet/byte synchronization to keep the slave bit counter syn-

chronous with the master clock generator. When the SS

pin is driven high, the SPI Slave

will immediately reset the send and receive logic, and drop any partially received data in

the Shift Register.

Master Mode When the SPI is configured as a Master (MSTR in SPCR is set), the user can determine

the direction of the SS

pin.

If SS

is configured as an output, the pin is a general output pin which does not affect the

SPI system. Typically, the pin will be driving the SS

pin of the SPI Slave.

If SS

is configured as an input, it must be held high to ensure Master SPI operation. If

the SS pin is driven low by peripheral circuitry when the SPI is configured as a Master

with the SS

pin defined as an input, the SPI system interprets this as another Master

selecting the SPI as a slave And starting to send data to it. To avoid bus contention, the

SPI system takes the following actions:

1. The MSTR bit in SPCR is cleared and the SPI system becomes a Slave. As a

result of the SPI becoming a Slave, the MOSI and SCK pins become inputs.

2. The SPIF Flag in SPSR is set, and if the SPI interrupt is enabled, and the I-bit in

SREG is set, the interrupt routine will be executed.

Thus, when interrupt-driven SPI transmission is used in Master mode, and there exists a

possibility that SS

is driven low, the interrupt should always check that the MSTR bit is

still set. If the MSTR bit has been cleared by a slave select, it must be set by the user to

re-enable SPI Master mode.

SPI Control Register – SPCR

• Bit 7 – SPIE: SPI Interrupt Enable

This bit causes the SPI interrupt to be executed if SPIF bit in the SPSR Register is set

and the if the Global Interrupt Enable bit in SREG is set.

• Bit 6 – SPE: SPI Enable

When the SPE bit is written to one, the SPI is enabled. This bit must be set to enable

any SPI operations.

• Bit 5 – DORD: Data Order

When the DORD bit is written to one, the LSB of the data word is transmitted first.

When the DORD bit is written to zero, the MSB of the data word is transmitted first.

Bit 76543210

SPIE SPE DORD MSTR CPOL CPHA SPR1 SPR0 SPCR

Read/Write R/W R/W R/W R/W R/W R/W R/W R/W

Initial Value00000000
