ATmega162/V

2513E–AVR–09/03

Extended Timer/Counter

Interrupt Flag Register –

ETIFR

(1)

Note: 1. This register contains flag bits for several Timer/Counters, but only Timer3 bits are

described in this section. The remaining bits are described in their respective Timer

sections.

• Bit 5 – ICF3: Timer/Counter3, Input Capture Flag

This flag is set when a capture event occurs on the ICP3 pin. When the Input Capture

set when the counter reaches the TOP value.

ICF3 is automatically cleared when the Input Capture Interrupt Vector is executed. Alter-

natively, ICF3 can be cleared by writing a logic one to its bit location.

• Bit 4 – OCF3A: Timer/Counter3, Output Compare A Match Flag

This flag is set in the timer clock cycle after the counter (TCNT3) value matches the Out-

put Compare Register A (OCR3A).

Note that a Forced Output Compare (FOC3A) strobe will not set the OCF3A Flag.

OCF3A is automatically cleared when the Output Compare Match A Interrupt Vector is

executed. Alternatively, OCF3A can be cleared by writing a logic one to its bit location.

• Bit 3 – OCF3B: Timer/Counter3, Output Compare B Match Flag

This flag is set in the timer clock cycle after the counter (TCNT3) value matches the Out-

put Compare Register B (OCR3B).

Note that a Forced Output Compare (FOC3B) strobe will not set the OCF3B Flag.

OCF3B is automatically cleared when the Output Compare Match B Interrupt Vector is

executed. Alternatively, OCF3B can be cleared by writing a logic one to its bit location.

• Bit 2 – TOV3: Timer/Counter3, Overflow Flag

The setting of this flag is dependent of the WGMn3:0 bits setting. In normal and CTC

modes, the TOV3 Flag is set when the timer overflows. Refer to Table 56 on page 129

for the TOV3 Flag behavior when using another WGMn3:0 bit setting.

TOV3 is automatically cleared when the Timer/Counter3 Overflow Interrupt Vector is

executed. Alternatively, TOV3 can be cleared by writing a logic one to its bit location.

Bit 76543210

ICF3 OCF3A OC3FB TOV3 – –ETIFR

Read/Write R R R/W R/W R/W R/W R R

Initial Value00000000
