127

ATmega162/V

2513E–AVR–09/03

16-bit Timer/Counter

Timer/Counter1 Control

Timer/Counter3 Control

• Bit 7:6 – COMnA1:0: Compare Output Mode for channel A

• Bit 5:4 – COMnB1:0: Compare Output Mode for channel B

The COMnA1:0 and COMnB1:0 control the Output Compare pins (OCnA and OCnB

respectively) behavior. If one or both of the COMnA1:0 bits are written to one, the OCnA

output overrides the normal port functionality of the I/O pin it is connected to. If one or

both of the COMnB1:0 bit are written to one, the OCnB output overrides the normal port

functionality of the I/O pin it is connected to. However, note that the Data Direction Reg-

ister (DDR) bit corresponding to the OCnA or OCnB pin must be set in order to enable

the output driver.

When the OCnA or OCnB is connected to the pin, the function of the COMnx1:0 bits is

dependent of the WGMn3:0 bits setting. Table 53 shows the COMnx1:0 bit functionality

when the WGMn3:0 bits are set to a normal or a CTC mode (non-PWM).

Bit 76543210

COM1A1 COM1A0 COM1B1 COM1B0 FOC1A FOC1B WGM11 WGM10 TCCR1A

Read/Write R/W R/W R/W R/W W W R/W R/W

Initial Value 0 0 0 0 0 0 0 0

Bit 76543210

COM3A1 COM3A0 COM3B1 COM3B0 FOC3A FOC3B WGM31 WGM30 TCCR3A

Read/Write R/W R/W R/W R/W W W R/W R/W

Initial Value 0 0 0 0 0 0 0 0

Table 53. Compare Output Mode, non-PWM

COMnA1/

COMnB1

COMnA0/

COMnB0 Description

0 0 Normal port operation, OCnA/OCnB disconnected.

0 1 Toggle OCnA/OCnB on Compare Match.

1 0 Clear OCnA/OCnB on Compare Match (Set output to low level).

1 1 Set OCnA/OCnB on Compare Match (Set output to high level).
