Electrical Characteristics
Absolute Maximum Ratings*
Operating Temperature.................................. -55°Cto+125°C
*NOTICE: Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Storage Temperature ..................................... -65°Cto+150°C
Voltage on Any Pin except RESET
with Respect to Ground .............................-1.0V to V
CC
+0.5V
Voltage on RESET
with Respect to Ground ....-1.0V to +13.0V
Maximum Operating Voltage ............................................ 6.6V
DC Current per I/O Pin ............................................... 40.0 mA
DC Current VCC and GND Pins ............................... 300.0 mA
DC Characteristics
T
A
=-40°Cto85°C, V
CC
= 2.7V to 6.0V (unless otherwise noted)
Symbol Parameter Condition Min Typ Max Units
V
IL
Input Low Voltage Except (XTAL, RESET)-0.5 0.3V
CC
(1)
V
V
IL1
Input Low Voltage
XTAL
-0.5 0.2 V
CC
(1)
V
RESET
V
IH
Input High Voltage Except (XTAL, RESET)0.7V
CC
(2)
V
CC
+0.5 V
V
IH1
Input High Voltage XTAL 0.7 V
CC
(2)
V
CC
+0.5 V
V
IH2
Input High Voltage RESET 0.85 V
CC
(2)
V
CC
+0.5 V
V
OL
Output Low Voltage
(3)
(Ports B, C, D)
I
OL
=20mA,V
CC
=5V
I
OL
=10mA,V
CC
=3V
0.6
0.5
V
V
OH
Output High Voltage
(4)
(Ports B, C, D)
I
OH
=-3mA,V
CC
=5V
I
OH
=-1.5mA,V
CC
=3V
4.3
2.2
V
I
IL
Input Leakage
Current I/O pin
V
CC
=6V,pin=low
(absolute value)
8.0 µA
I
IH
Input Leakage
Current I/O pin
V
CC
= 6V, pin = high
(absolute value)
8.0 µA
RRST Reset Pull-up 100.0 500.0 kΩ
R
I/O
I/O Pin Pull-up Resistor 35.0 120.0 kΩ
I
CC
Power Supply Current
Active4MHz,V
CC
=3V 5.0 mA
Idle 4 MHz, V
CC
=3V 2.0 mA
Power-down, V
CC
=3V
WDT enabled
(5)
20.0 µA
Power-down, V
CC
=3V
WDT disabled
(5)
10.0 µA
