37
AT90S/LS4433
1042G–AVR–09/02
Timer/Counter1 Control
Register A – TCCR1A
• Bits 7, 6 – COM11, COM10: Compare Output Mode1, Bits 1, and 0
The COM11 and COM10 control bits determine any output pin action following a
Compare Match in Timer/Counter1. Any output pin actions affect pin OC1 (Output
Compare pin 1). This is an alternative function to an I/O port, and the corresponding
direction control bit must be set (one) to control an output pin. The control configuration
is shown in Table 10.
In PWM mode, these bits have a different function. Refer to Table 11 for a detailed
description.
• Bits 5..2 – Res: Reserved Bits
These bits are reserved bits in the AT90S4433 and always read as zero.
• Bits 1, 0 – PWM11, PWM10: Pulse Width Modulator Select Bits
These bits select PWM operation of Timer/Counter1 as specified in Table 11. This mode
is described on page 41.
Bit 7 6 5 4 3 2 1 0
$2F ($4F) COM11 COM10 ––––PWM11 PWM10 TCCR1A
Read/Write R/W R/W R R R R R/W R/W
Initial Value 0 0 0 0 0 0 0 0
Table 10. Compare 1 Mode Select
COM11 COM10 Description
0 0 Timer/Counter1 disconnected from output pin OC1
0 1 Toggle the OC1 output line.
1 0 Clear the OC1 output line (to zero).
1 1 Set the OC1 output line (to one).
Table 11. PWM Mode Select
PWM11 PWM10 Description
0 0 PWM operation of Timer/Counter1 is disabled
0 1 Timer/Counter1 is an 8-bit PWM
1 0 Timer/Counter1 is a 9-bit PWM
1 1 Timer/Counter1 is a 10-bit PWM
