121
AT90S/LS4433
1042G–AVR–09/02
Data Sheet
Change Log for
AT90S/LS4433
This section containes a log on the changes made to the data sheet for AT90S/LS4433.
All refereces to pages in Change Log, are referred to this document.
Changes from Rev.
1042E-09/01 to Ref.
1042F-03/02
1 Updated minimum AREF Voltage on page 5 and page 64.
2 Corrected VBOT Max for BODLEVEL = 1 in Table 4 on page 22.
3 Updated Corporate Template.
Changes from Rev.
1042F-03/02 to Ref.
1042G-09/02
1 Added wathermark “Not recommended for new designs. Use ATmega8”.
2 Added Errata Sheet to the Data Sheet.
