117
AT90S/LS4433
1042G–AVR–09/02
Packaging Information
32A
8.75 (0.344)
8.75 (0.344)
0.45 (0.018)
0.30 (0.012)
PIN 1 ID
0.80 (0.0315) BSC
6.90 (0.272)
0.20 (0.008)
0.09 (0.004)
0.75 (0.030)
0.45 (0.018)
1.20 (0.047) MAX
0.15 (0.006)
0.05 (0.002)
32-lead, Thin (1.0mm) Plastic Quad Flatpack
(TQFP), 7x7mm body, 2.0mm footprint, 0.8mm pitch.
Dimensions in Millimeters and (Inches)*
JEDEC STADARD MS-026 ABA
PIN 1
*Controlling dimensions: Millimeters
0º~7º
7.10 (0.280)
9.25 (0.364)
9.25 (0.364)
SQ
