116
AT90S/LS4433
1042G–AVR–09/02
Ordering Information
Power Supply Speed (MHz) Ordering Code Package Operation Range
2.7 - 6.0V 4 AT90LS4433-4AC
AT90LS4433-4PC
32A
28P3
Commercial
(0
°Cto70°C)
AT90LS4433-4AI
AT90LS4433-4PI
32A
28P3
Industrial
(-40
°Cto85°C)
4.0 - 6.0V 8 AT90S4433-8AC
AT90S4433-8PC
32A
28P3
Commercial
(0
°Cto70°C)
AT90S4433-8AI
AT90S4433-8PI
32A
28P3
Industrial
(-40
°Cto85°C)
Package Type
32A 32-lead, Thin (1.0 mm) Plastic Quad Flat Package (TQFP)
28P3 28-lead, 0.300" Wide, Plastic Dual Inline Package (PDIP)
