WinLink User and Installation Guide Version 1.795 3-29
station should be plugged into the second trunk, as in the left hand
side of Figure
2-7 above.
Apart from the above difference, the link installation including the
remaining part of the IDU installation and connection to the ODU
proceeds as described as above.
Connecting the Ground to the IDU
Connect an 18AWG grounding cable to the grounding terminal of the
device. The device should be permanently connected to the ground.
Connecting Power to an IDU
AC power is supplied to the WinLink™ 1000 IDU through a standard
IEC 60320 connector.
AC power should be supplied via a 1.5m (5 ft) standard power cable
terminated by a IEC 60320 socket. A cable is provided with the unit.
To connect AC power to an IDU:
Connect the power cable socket to the power connector on the
WinLink front panel.
• Connect the power cable plug to the mains outlet.
The unit turns on automatically upon connection to the mains.
To connect DC power to an IDU
A special 3-prong socket for DC power connection is supplied with the
unit.
Connecting Power to an O-PoE
AC power is supplied to the O-PoE via a 3m (10 ft) 3 wire AC cable
attached to the unit (pigtail). The AC cable is provided with no
termination.
To connect AC power to an O-PoE:
Connect the power cable to a protected/shielded AC mains outlet.
The AC mains outlet should be provided with circuit breaker rated 5A
according to the local national electrical code.
The unit will be turned on automatically upon connection to the mains.
To maintain Overvoltage (Installation) Category II, install a suitable
surge suppressor device in the branch circuit to limit expected
transients to Overvoltage Category II values.
The limits are based on IEC60664 and are also located in Table 2H of
UL60950 (for mains ≤ 150V, the transient rating is 1500V;
Warning
