28. COMMUNICATION PROTOCOL

28.1. General information

A. A character protocol scale-terminal has been designed for

communication between RADWAG scales and external devices

via RS-232 interface.

B. It consists of commands sent from an external device to the scale

and a responses from a scale.

C. Responses are sent every time after receiving a command

(reaction for any command).

D. Using commands allows users to receive some information about

the state of scale and/or influence the operation e.g.: Requesting

weighing results, display control.

28.2. Inventory of RS commands

Commands

Description of commands

Zeroing

Tarring

Get tare value

Set tare value

Send the stable result in basic unit

Send the result immediately in basic unit

Send the stable result in current unit

SUI

Send the result immediately in current unit

Switch on continuous transmission in basic unit

Switch off continuous transmission in basic unit

CU1

Switch on continuous transmission in current unit

CU0

Switch off continuous transmission in current unit

Set lower threshold

Set upper threshold

ODH

Read lower threshold

OUH

Read upper threshold

Send all implemented commands
