27.7.6. Database of warehouses
Procedure:
• Enter < Databases> according to ch. 27 of this manual,
• Enter <
Warehouses> and press the required position.
Warehouse record:
Name
Warehouse name
Code
Warehouse code
Description
Additional warehouse description
27.7.7. Database of labels
The database comprises patterns of labels which users can attribute
to products or contractors to operate in labelling mode.
Procedure:
• Enter < Databases> according to ch. 27 of this manual,
• Enter <
Labels> and press the required position.
Label record:
Name
Label name
Code
Label code
Label pattern*
Label printout pattern
*) Ways of designing and sending patterns to a scale can be found
in APPENDIX C of this manual.
