• Give a date before which data need to be removed and confirm

it by pressing

Caution:

If a user enters a date from the protected period the program displays

a message box: <Wrong value>.

• After entering a date beside protected period the program displays

a message box: <Are you sure you want to delete?>,

• After it is confirmed by

the program will start removing data

and after completing it displays the number of deleted records,

• Press

to leave.

27.5. Printing items from databases

Users can print any record in databases.

Procedure:

• Enter the submenu < Databases> according to ch. 27 of the manual,

• Enter <

Products> and press the required item,

• After editing the required record press

in the top bar of the display,

• If a printer is connected information about the selected product

is printed.

Notice:

Default printout patterns for printing records from different databases

are described in ch. 16.2.3 of this manual.

27.6. Export a database to a file

An operator after a series of weighings can export a database to a file

using a pendrive.

Procedure:

• Connect a pendrive to USB,
