Notice:

Adding new records in databases is possible only by logged-in

administrators. It does not concern the database of weighings.

27.3. Deleting items in databases

Procedure:

• Enter < Databases> according to ch. 27 of the manual,

• Enter <

Products>,

• Give a long press to the item, then the context menu is displayed,

• Press <Delete>, then a message is displayed:

<Are you sure you want to delete?>,

• Confirm it by pressing

Caution:

Deleting records in databases is possible only by logged-in administrators.

It does not concern the database of weighings.

27.4. Deleting older data

A user after logging on as administrator can delete older position

in the database of weinghings <

Weighing / Alibi>.

Caution:

Factory settings prevent users from deleting weighings that are up to

one year old. Because of incompatible regulations in different countries

concerning the time of protecting data this period can be modified by

distributors.

Procedure:

• Enter the submenu < Databases> according to ch. 27 of the manual,

• Enter <

Delete older data>, then an editing field is displayed

<Give year> with the screen keyboard,
