27.1.2. Quick code search

Procedure:

• Enter < Databases> according to ch. 27 of the manual,

• Enter <

Products>,

• Press

, then an editing field appears <Search by code>

with the screen keyboard,

• Inscribe the name of a product or its part and press

• The program will automatically edit the required product.

27.1.3. Weighing date search

Procedure:

• Enter < Databases> according to ch. 27 of the manual,

• Enter <

Weighings>,

• Press

, then an editing field appears <Specify year>

with the screen keyboard,

• Inscribe: year, month, day, hour, minute of weighing and confirm

it by pressing

• The program will automatically display the list of weighings putting

at the top the position with the entered date.

27.2. Adding new items in databases

Procedure:

• Enter < Databases> according to ch. 27 of this manual,

• Enter database <

Products>,

• Press

, then the message is displayed: <Create new record?>,

• Confirm it by pressing

, the program automatically enters

edition of new record.
