In order to enter <

Databases>, press and choose

Databases>.

27.1. Searching databases

Users can quickly search databases according to the following criteria:

• Name,

•

Code.

The quick search according to the criteria above is applicable for databases

of: operators, products, contractors, packages, warehouses and labels.

Additionally users can search the weighing database according to <

weighing date>.

27.1.1. Quick name search

Procedure:

• Enter < Databases> according to ch. 27 of the manual,

• Enter <

Products>,

• Press

, then an editing field appears <Search by name>

with the screen keyboard,

• Inscribe the name of a product or its part and press

• The program will automatically edit the required product.
