• Standard deviation:

()

∑

−=

XDD

26.1. Starting the working mode

Procedure:

• While in the main window press in the top bar, then you will

see a submenu <Working modes> comprising a list of modes,

• Choose mode <

Comparator>, program automatically returns

to the main window displaying in the top bar the name of selected

working mode,

• Concurrently on the workspace of the window a message is

displayed: <Start control>.

26.2. Procedure

Caution:

This example description concerns only an ABBA series of measurements.

• Start testing by pressing screen function button

(process start)

situated in the lower part of the display,

• In the window workspace following information are displayed:

Put A1 - Hints for operators to follow

P 1/10 - Measurement series : 1 –series in progress number,

10 – number of measurement series to perform

DX=0 - Average difference of indications

S=0 - Standard deviation value

Assort - Product name from the assortment database

Tare - Entered tare value (packages)

Pack - Package name from the database of packages
