If a user has changed the operating mode to another follow the actions
below:
• While in the main window press the icon with mode name placed on
the top bar on the left then submenu comprising all accessible working
modes <Working Modes> opens,
• Choose <
Weighing>, program automatically returns to the main
window displaying icon
in the top bar.
24. WORKING MODES – COUNTING PIECES
Counting pieces is work mode allowing to count pieces on the basis
of the standard unit mass of a single piece set on the scale or fetched
from the database.
Notice:
If counting pieces is performed in an additional container it should be tarred.
24.1. Starting the working mode
Procedure:
• While in the main window press in the top bar, then you will
see a submenu <Working Modes> comprising a list of modes,
• Choose < Counting Pieces>, program automatically returns
to the main window displaying icon
in the top bar,
• The weight unit is automatically changed to „pcs” and two screen
buttons on the right side appear:
Enter piece mass
Estimate piece mass
71
