22.8. Selecting the series type
It concerns the < Comparator> working mode
Procedure:
• Enter group of parameters <
Working modes> according
to ch. 22 of this manual: „
Comparator / Method”
and then choose the right method.
Accessible methods:
• ABBA
• ABA
22.9. Declaration of the number of measurement series
It concerns the < Comparator> working mode
Procedure:
• Enter group of parameters <
Working modes> according
to ch. 22 of this manual,
• Choose: „
Comparator / Number of measurements”
then an editing field will appeare < Number of measurements>
with the screen keyboard,
• Inscribe the required value and confirm it by pressing
.
23. WORK MODE - WEIGHING
The < Weighing> mode is the standard working mode allowing
to perform weighings and saving them in the database
<
Weighings / Alibi>.
23.1. Starting the working mode
The <
Weighing> mode is the standard working mode.
70
