− If parameter < Mode> is set to <Number> use the screen

keyboard to enter the required counter value as a threshold to

trigger off printing CC labels.

• Confirm the changes introduced by pressing .

22.6. Statistics

All statistics are continuously updated after each measurement is saved

in the scale memory. Statistics can be calculated globally (does not depend

on the selected product) or separately for every product from the assortment

database. It can be set in parameters <

Statistics>.

Procedure:

• Enter < Working modes> parameter group as described

in chapter 22 of the manual,

• Enter the required working mode and choose <

Statistics>

and then set the required option.

Options:

Global

- global statistics,

Product

- statistics for every product.

Notice:

In case of operation with <

Statistics> set to <Product> bare in mind

that after restarting only statisics of the last weighed product are recovered.

22.7. Automatic correction of reference mass

It concerns the

Counting pieces> working mode

Working mode <

Counting Pieces> comprises a special function

Automatic correction of reference mass>, that can be used for

correcting the unit mass <SMP>.
