- Cumulative label of cumulative labels printout is initiated

by pressing

Mass

- Cumulative label of cumulative labels printout is initiated by

exceeding the value set in parameter <

Threshold>.

The value is treated as the total from single weighings,

Number

- Cumulative label of cumulative labels printout is initiated by

exceeding the value set in parameter <

Threshold>.

The value is treated as the number of single weighings,

*) Manual printing of cumulative labels can be done in two ways depending

on the button used:

Printing followed by zeroing label counter or the total mass

Printing without zeroing label counter or the total mass

By default setting button

is accessible in the bottom part of the

display but activating the button

can be done in subm

„

enu:

Parameters / Display / Actions”

(see ch. 17.2 of the manual).

For automatic printout cumulative labels of cumulative (CC)

labels counters and total mass variables are always zeroed.

• Confirm the changes by pressing

and go to parameter

Threshold> then <Threshold> window appears with

the screen keyboard,

• Set the appropriate value for automatic triggering CC labels:

− If parameter < Mode> is set to <Mass> then enter the

required value of total mass to exceed in order to print the

CC label,
