• Enter the required number od cumularive labels and confirm

by pressing

22.5.4. Automatic triggering of cumulative labels

Users have access to the function of automatic triggering of printing

cumulative labels after setting parameters <

Mode> and

Threshold>.

Procedure:

• Enter < Working modes> parameter group as described

in chapter 22 of the manual,

• Enter the required working mode and choose: „

Labelling mode /

C label automatic triggering / Mode” and then set the

required option:

None

- Cumulative label printout is initiated by pressing

Mass

- Cumulative label printout is initiated by exceeding the

value set in parameter <

Threshold>. The value

is treated as the total from single weighings,

Number

- Cumulative label printout is initiated by exceeding the

value set in parameter <

Threshold>. The value

is treated as the number of single weighings.

*) Manual printing of cumulative labels can be done in two ways

depending on the button used:

Printing followed by zeroing label counter or the total mass

Printing without zeroing label counter or the total mass
