Total sum
- Summing up all subsequently entered tare values
Autotare
- Automatic tare mode together with mode
<Sum of all>
22.5. Labelling mode
The labelling system is intended to print labels for marking weighed goods
e.g. a packing process. The program can print standard labels for single
products, cumulative labels for sticking to bulk containers and cumulative
labels for cumulative labels for sticking to the large transport containers
holding bulk containers.
In submenu <
Labelling mode> there are accessible following special
functions:
Number of labels
No. of cumulative labels
No. of CC labels
C label automatic triggering
CC label automatic triggering
22.5.1. Setting of the number of labels to print
In the parameter <
Number of labels> user defines the amount
of labels. They are printed on the printer connected to the weight.
Procedure:
• Enter parameters group < Working Modes> according
to ch. 22 of this manual,
63
