22. SPECIAL FUNCTIONS OF WORKING MODES
WPY/KO scales can operate in following work modes:
Weighing
Counting pieces
Deviations
Comparator
In settings of different working modes special functions that allows adopting
the operation to the customers’ needs:
Special functions: Weighing
Counting
pieces
Deviations Comparator
Save Mode + + + +
Down-weighing + + + -
Checkweighing + + + +
Tare mode + + + +
Labelling mode + + + -
Statistics + + + +
Automatic correction
of reference mass *
- + - -
Method - - - +
Number of measurements - - - +
+ / - Function available / non-available in the given mode.
Work modes can be configured in < Working Modes>.
To enter submenu <
Working Modes>, press
and then
: „ Parameter / Working Modes”.
Notice:
1. First left screen button
(local settings) in the main window of
every working mode is ascribed to access settings of current mode.
