20.3. Sound signal

Procedure:

• Enter < Others> according to ch. 20 of this manual, < Beep>

and set accordingly.

Settings:

None

- Sound for buttons and proximity sensors disabled

Buttons

- Sound for buttons enabled

Sensors

- Sound for proximity sensors enabled

All

- Sound for buttons and proximity sensors enabled

20.4. Touch panel calibration

Touch panel calibration is required when inappropriate operation is

recognized. E.g. the reaction in a different place than the touching point.

Procedure:

• Enter submenu < Others> according to ch. 20 of this manual,

• Select <

Touch Screen Calibration> and then an editing field

appears,

• Using a thin and soft pointer press (keep pressed for some time)

in the point where the cross appears, after indicating the 4

place

confirm changes by pressing

21. CUSTOMER CALIBRATION

An option only for non-verified scale

Scales require to recalculate internal divisions to more suitable ones (e.g.

g, kg etc.). In order to do this they require a calibration factor. It is adjusted

during the calibration procedure using a mass standard. Calibration should

be made when weighing a standard mass shows a different mass value.
