17.1.1. Display patterns
The main application window comprises a work area including information
that can be freely configured by a user.
Procedure:
• Enter < Display> according to ch. 17 of this manual,
• Choose: „
Text information / Displaying pattern”, then an
editing field with prompted value is displayed together with the screen
keyboard,
• Modify the pattern if necessary and confirm the changes by pressing
.
Notice:
There are additional buttons in the bottom line of the screen keyboard.
They can be used while modifying a display pattern. :
Screen keyboard on/off
Reading a display pattern from a *.lb file (button active while
connecting a USB pendrive). *.lb files with the default patterns
of display in every language version are accessible on the CD
attached to the device
List of variables for display patterns (see the list in APPENDIX A
of this manual)
Clear the editing field
Default display pattern:
Assort: {50}
Tare: {9}{11} Pack: {80}
N: {15} Sum: {16}{10}
Min: {12}{10} Max: {13}{10}
Series: {14}
