17. DISPLAY

Users can adapt the main display and visible information to their needs.

All parameters of the display can be found in the parameters’ group

Display>.

Entering <

Display> can be made in two ways:

• Direct pressing in the work area of the main display,

• Pressing and then: „ Parameters / Display”.

Inventory of parameters of the main display:

Text information

Buton functions

Show all platforms

Bargraph Type

17.1. Text strings

In < Text information> users can set:

Display pattern

Screen font

Font size

Bold font
