• RS 232 (COM1),

• RS 232 (COM2),

• Tcp.

16.5.2. Communication protocol frame

PUE 7 weighing indicator with following displays:

• WD display,

• WWG display.

To start cooperation of PUE 7 with displays go to parameter <

Sample>

and define an appropriate communication protocol.

Procedure:

• Enter parameters’ group < Devices> according to ch. 16 of this

manual,

• Choose „

Additional display / Sample” then the editing field

<Sample> with the screen keyboard appears,

• Inscribe the required frame pattern using the screen keyboard or

choose the it from the list after pressing

Specified patterns for displays:

{141}

- Protocol pattern for WD displays

{142}

- Protocol pattern for WWG display

• Confirm the changes by pressing .

Notice:

In default settings parameter <

Sample> has ascribed {141}

(WD display).
