16.4.2. Procedure of attributing the card number to an operator
To use a transponder card to log on an operator the card needs to be
ascribed to the operator in the database of operators.
Procedure:
• Connect the transponder card reader to the required communication
port (RS 232 COM1 or RS 232 COM2),
• Choose a communication port for the reader (see ch. 16.4.1 in this
manual),
• In submenu < Communication> set the baud rate to the same
as in the reader (default 9600b/s),
• Enter the database of operators and edit the selected operator going
to the field <
Card Number>,
• After entering the field < Card Number> you will see the editing
field <Card Number> with the screen keyboard,
• Having approached the card to the reader the program automatically
displays in editing field <Card Number> the number of read card,
• Confirm the number by pressing and return to weighing.
16.5. Additional display
16.5.1. Additional display port
Procedure:
• Enter parameters group < Devices> according to ch. 16
of this manual, select „
Additional display / Port”
and then choose an appropriate option from the list.
Communication with additional displays can be performed via following
ports:
