• Communication port for a barcode scanner,

• Offset setting (a number of characters that are omitted while reading),

• Code length (number of characters that are analysed counting from

the offset).

Notice:

In submenu <

Communication> set the baud rate (default 9600b/sec).

The detailed description of cooperation scale – barcode scanner can be

found in APPENDIX F in this manual.

16.3.1. Port for barcode scanner

Procedure:

• Enter < Devices> according to ch.16 of the manual, choose

„

Barcode reader / Port” and then set the appropriate value.

Barcode scanners can be connected to:

• RS 232 (COM1),

• RS 232 (COM2),

16.3.2. Offset

It outlines the first character that is significant for searching the assortment

database. All preceding characters are skipped.

Procedure:

• Enter < Devices> according to ch.16 of the manual,

• Choose „

Barcode reader / Offset” , then the screen

keyboard is displayed,

• Write a new offset and confirm it by pressing
