16.2.2. Printer code page

Procedure:

• Enter parameters <

Devices> as described in chapter 16

of the manual,

• Choose „

Printer / Code Page” then the screen keyboard

will be displayed,

• Write the required code page and confirm by pressing

Notice:

The default value is 1250 – code page for Middle-East Europe.

16.2.3. Patterns for printouts

Enter < Printouts> to define printout patterns.

Procedure:

• Enter parameter group <

Devices> as described in chapter

16 of the manual, then choose „

Printer / Printouts”,

• After editing a pattern a memo box with the default content and the

screen keyboard,

• Modify the pattern according to your requirements and confirm it by

pressing

Notice:

There are additional buttons in the bottom line of the screen keyboard.

They can be used while modifying a printout pattern.:

Screen keyboard on/off

Reading a printout pattern from a *.lb file (button active while

connecting a USB pendrive)

List of variables for printout patterns (see the list in APPENDIX A

of this manual)

Clear the editing field
