16.1.2. Computer address
Procedure:
• Enter < Devices> parameter group as described in chapter
16 of the manual,
• Choose „
Computer / Address” then the window <Address>
with the screen keyboard appears,
• Enter the required address and confirm it by pressing
.
16.2. Printer
In < Printer> submenu users can:
• Setting communication with a printer,
• Setting code page of a printer,
• Setting patterns of printouts.
To enter <
Printer>, press and then:
„ Parameters / Devices / Printer”
16.2.1. Printer port
Procedure:
• Enter < Devices> parameter group as described in chapter 16
of the manual, choose „
Printer / Port” and then select an
appropriate option.
Printers can be attached to:
• RS 232 (COM1),
• RS 232 (COM2),
• USB,
• Tcp.
