If AUTOZERO is disabled zero is not corrected automatically. However,
in particular cases, this function can disrupt the measurement process e.g.
slow pouring of liquid or powder on the weighing pan. In this case, it is
advisable to disable the autozero function.
Procedure:
• Enter < Weighing> according to ch. 14 of the manual, select
<
Autozero> and then set an appropriate value.
Accessible settings:
NO
- Autozero off
YES
- Autozero on
14.4. Minimum weight for different functions (LO)
Parameter <LO THRESHOLD> is associated with automatic weighing.
Next weighing will not be saved until the indication goes under the
THRESHOLD LO (net).
Procedure:
• After entering <
Threshold Lo> according to ch. 14 of this manual
a keyboard is displayed,
• Inscribe LO and confirm by pressing
.
15. COMMUNICATION
The scale can communicate with external devices via different ports:
• COM 1 (RS232),
•
COM 2 (RS232),
•
Ethernet,
•
Tcp.
