9.2.3. Communication

Icon Description Value

COM1 -

Baud Rate 9600

Data bits 8

Stop bits 1

Parity None

COM2 -

Baud Rate 9600

Data bits 8

Stop bits 1

Parity None

Ethernet -

DHCP No

IP Address 192.168.0.2

Subnet mask 255.255.255.0

Gateway 192.168.0.1

Tcp -

Port 4001
