31. TECHNICAL PARAMETERS

Scale type:

WPY

500/KO

WPY

1000/KO

WPY

2000/KO

Maximal range 510kg 1100kg 2100kg

Readability 5g 10g 20g

Comparation range 0....510kg 0....1100kg 0....2100kg

Repeatability 5g 10g 20g

Recommendations for rating

weights OIML R111

500kg - M1 1000kg - M1 2000kg - M1

Platform size 1000 x 1000mm 1200 x 1500mm

Stabilization time 5....10s

Maximal temperature change 5°C/24h

Supply 110÷230VAC 50/60Hz – 10,5÷15VDC

Temperature operation range -10°C to +40°C

Storage temperature -25°C to +70°C

32. ERROR MESSAGES

Err2

- Value beyond the zero range,

Err3

- Value beyond the tare range,

Err8

- Tarring / zeroing operation time exceeded,

NULL

- Zero value from the AD converter,

FULL

- Measurement range overflow,

Display range overflow,

- Start mass error, the mass on the weighing platform is

beyond the acceptable range (-5% to +15% of start mass)
