Configuring the Screen Saver to Start Automatically
About this task
The screen saver helps to protect your monitor from burn-in without switching it off. This can be useful in
situations when you stop using your Scopia XT Endpoint for IP Office for a relatively short period of time.
You can do this procedure from the endpoint itself or from the XT Endpoint web interface.
Procedure
1. Access the screen saver settings as follows:
•
From the endpoint's main menu, select Configure > General.
•
From the XT Endpoint web interface, select the Basic Settings tab.
Figure 56: Configuring screen saver settings
2. Select Yes from the Screen Saver list.
3. Set the time after which the screen saver automatically starts on the display in the Minutes
field.
4. From the web interface only, select Save.
Configuring Video Connections
There are a number of settings which affect the way the camera accepts input and the way the monitors
display video.
