Figure 55: Setting regional information
3. Define regional settings as described in Table 18: Configuring regional information on page
93.
Table 18: Configuring regional information
Field Name Description
System name Enter the name that will appear in the local endpoint interface and in
the remote endpoint interface (if connected).
Country Select the country in which the local system is located. Once the
country is selected, the other fields are populated automatically.
Language Select the language used in the XT Endpoint endpoint's interface.
Audio coding Select the European or US coding.
Video frequency The video refresh frequency depends on the country, and may
assume the values of 50Hz or 60Hz. You can select the video
frequency automatically or manually. If set to automatic, the system
assigns the value depending upon the selected country. In Japan,
the frequency depends on the country area (east or west); thus in
Japan the system administrator must select manually the correct
value related to the geographic location.
4. Select Save.
