Figure 54: Setting the time zone
Table 17: Configuring time zone related settings
Field Name Description
Time zone list Select the time zone to which the system belongs.
Enable daylight time Set the daylight or summer time field to Yes or No
according to the current daylight-saving status of your
time zone.
Start (dd/mm) Set the day and month to indicate when daylight
saving times start.
Stop (dd/mm) Set the day and month to indicate when daylight
saving times end.
3. From the web interface only, select Save.
Remotely Setting Regional Information
About this task
You must configure the region-related settings: the country and language. You also need to configure
audio coding and video frequency, because your video network depends on the local infrastructure. The
system suggests the optimal values for audio coding and video frequency when you enter the country
value.
You may have set some of these fields in the Quick Setup procedure, since this is part of the basic
required settings (for details, see
Accessing the Quick Setup Procedure on page 75). You can modify
these settings at any time from the endpoint or the web interface.
Procedure
1. Access the XT Endpoint web interface, as described in
Accessing XT Endpoint Web
Interface on page 55.
2. Select Administrator Settings > System > Location.
