Field Name Description
Use Default NTP
Server
If your organization uses an external Network Time Protocol (NTP)
server for synchronizing the system clock, select Yes. If your
organization uses one or two internal NTP servers for that purpose,
select No and enter the server IP address in fields Server 1 and/or
Server 2.
Refresh time Indicates the period of time after which the system contacts the NTP
server to refresh the clock.
3. From the web interface only, select Save.
Setting the Time Zone
About this task
You can set the time zone from your endpoint or the XT Endpoint web interface.
Before you begin
If configuring from the endpoint, you must first enable advanced configuration, as described in
Maintaining the XT Endpoint Locally from the Endpoint on page 66.
Procedure
1. Access the time zone settings as follows:
•
From the XT Endpoint web interface, select Administrator Settings > System > Date
& Time > Time Zone.
•
From the endpoint's main menu, select Configure > Advanced > System > Date &
Time > Time Zone.
You need to enter the PIN required to access the Advanced settings. The default PIN
is 1234.
2. Configure settings as described in Table 17: Configuring time zone related settings on page
92.
