Table 1: Physical device specifications
Scopia XT Endpoint for IP Office
System power requirements 100-240 VAC, 50/60 Hz, 1.8 A Max. for XT Codec
Unit and AC direct for the monitor
Maximum power consumption 100W, AC input 115VA (341 BTU/hr) at 40°C
Operating temperature 0°C to 40°C (32°F to 104°F)
Relative humidity 5% to 90% non-condensing
Storage temperature -40°C to 70°C (-40°F to 158°F), ambient
Physical dimensions and Net Weight Height: 49.5cm (19.5"), Width: 54cm (21.5"); Depth
25cm (9.9")
Weight: 10 kg (22.1 lb)
Camera
Physical dimensions and Net weight
Height: 15.2cm (6.0"), Width: 25cm (9.8"); Depth
13.5cm (5.3")
Weight: 1.6 kg (3.5 lb)
Microphone Pod
Physical dimensions and Net weight
Diameter: 14cm (5.5"), Weight: 0.3 kg (0.7 lb)
Microphone Pod capabilities 3-way Microphone Pod:
360º range
Up to 2 cascaded pods
Frequency response: 50 – 22,000 Hz
Table 2: Video, audio and control capabilities on page 9 lists the protocols and software
requirements.
Table 2: Video, audio and control capabilities
Scopia XT Endpoint for IP Office
Signaling protocols H.323, SIP, ISDN (in conjunction with Scopia Gateway)
Video codecs H.263, H.263+, H.263++,H.264, H.264 SVC, H.264 High Profile, H.264
High Profile SVC
Dual video H.239 (H.323); BFCP (SIP)
HDMI input formats 1920 x 1080 @ 25, 30, 50, 60fps (optional)
1280 x 720 @ 25, 30, 50, 60fps
720 x 576 @ 50fps
720 x 480 @ 60fps
640 x 480 @ 60fps
