Figure 49: Configuring SIP settings
2. Configure parameters as described in Table 14: Configuring SIP-related parameters on page
84.
Table 14: Configuring SIP-related parameters
Parameter Description
User Enter the extension number of the user, as
configured in IP Office.
When connecting over SIP, this name is displayed
on the monitors participating in the videoconference.
Authentication Name Enter the user's Name, as configured in IP Office.
Authentication Password Enter the user's Login Code, as configured in IP
Office.
UDP/TCP Listening Port Enter the same port number used by IP Office for
receiving inbound SIP calls. By default, port 5060 is
used.
Transport Outbound Call Select UDP.
