Table 13: Configuring IP addresses
Field Name Description
IP address Enter the system static IP address here, used for accessing and
managing the system.
If the system retrieves its IP address automatically, this field
displays the IP address assigned to the system.
Subnet mask Enter the subnet mask associated with the IP address.
If the system retrieves its IP address automatically, this field
displays the subnet mask that has been assigned.
Gateway Enter the default gateway static IP address. The gateway is used to
route information between two subnets, for example, between the
headquarters and a partner site.
If the system gets its IP address automatically, this field displays the
gateway IP address assigned to the system.
DNS Enter the DNS server IP address. The DNS server in your network
resolves domain names in your network and translates them into IP
addresses.
If the system gets its IP address automatically, this field displays the
assigned DNS server IP address.
3. To configure your gatekeeper's settings, select Next and continue with Configuring
Gatekeeper Settings on page 81.
If you are not using a gatekeeper in your deployment, select Next > Done.
Configuring Gatekeeper Settings
About this task
This is typically not relevant for IP Office deployments. Configure only if you are using a gatekeeper in
your deployment.
If you are not using a gatekeeper in your deployment, select Done.
A gatekeeper routes audio and video H.323 calls by resolving dial strings (H.323 alias or URI) into the IP
address of an endpoint, and handles the initial connection of calls. If your Scopia XT Endpoint for IP
Office works in conjunction with a gatekeeper, configure gatekeeper-related settings as described in this
procedure.
This procedure completes the basic system configuration.
If you are modifying these settings after initial setup, navigate to Configure > Network > H.323 from the
Main menu. For more information, see Registering the Scopia XT Endpoint for IP Office with a
Gatekeeper on page 120.
Before you begin
This procedure is performed as part of the basic configuration after Configuring Network Settings on
page 79. Consult with your network administrator to configure these fields.
