Registering the Scopia XT Endpoint for IP Office to Obtain a
License Key
About this task
Register your XT Endpoint to obtain your license key to activate the features of the XT Codec Unit, and
receive a number of additional benefits:
•
Notification of software updates and new features availability.
•
Be the first to know about product support alerts.
•
Access to Radvision’s user-community.
You can obtain other license keys in the same way, when you need them to enable optional features in
the XT Codec Unit, such as increased bandwidth or the embedded MCU, depending on the model. For
details, see Installing and Enabling Licenses which Extend System Functionality on page 69.
Procedure
1. Open the envelope that came with the XT Endpoint.
2. Locate the serial number and the product key in the letter inside the envelope. The serial
number is printed on a label affixed at the back of the XT Codec Unit.
You can find the user code (and the serial number) by selecting Configure > About from the
Main menu.
3. From your computer's Internet browser, navigate to
http://licensing.radvision.com/.
4. Complete the online registration form and enter the serial number (or the user code) AND the
product key.
The web registration form returns an active license key.
5. Write down the license key and keep it in a safe place for future use.
6. Use the license key to enable the software, as described in:
•
Remotely Enabling the License from the Web Interface on page 70
•
Enabling the License from the Scopia XT Endpoint for IP Office on page 73
Installing and Enabling Licenses which Extend System
Functionality
About this task
You can purchase licenses to extend the functionality of the Scopia XT Endpoint for IP Office, such as
upgrading the video resolution.
Table 12: Scopia XT Endpoint for IP Office Software Options on page 70 lists the various license
options available for purchase to extend the system’s functionality.
