Figure 39: Advanced configuration screen
6. We recommend changing the default administrator password, as described in Setting the
Administrator PIN Code for the XT Endpoint on page 89.
Registering and Enabling your Scopia XT Endpoint for IP
Office license
About this task
To activate the features of your XT Endpoint, you first register the product to obtain your license key, and
then enable the license. Follow the workflow described in this section.
If you do not yet have your license key, you can set up the system in demo mode for a period of 24
hours. After this time, you must enable your license key to use the system.
Procedure
1. Register your system to activate your license key, as described in
Registering the Scopia XT
Endpoint for IP Office to Obtain a License Key on page 69.
2. Enable the license from either the endpoint or the web interface:
•
Remotely Enabling the License from the Web Interface on page 70
•
Enabling the License from the Scopia XT Endpoint for IP Office on page 73
3. If you are enabling licenses with additional features, such as upgrading the video resolution,
see Installing and Enabling Licenses which Extend System Functionality on page 69.
