Important:
The code and icon do not appear when the default code, 01, is used.
6. Set the code and exit by doing one of the following:
•
In the web interface, select Finish.
•
In the endpoint, press OK.
Maintaining the XT Endpoint Locally from the Endpoint
About this task
To perform advanced configuration and maintain the Scopia XT Endpoint for IP Office from the endpoint
itself, you must first perform this procedure to access advanced settings. For example, you can upgrade
the XT Endpoint. For more information about maintaining the XT Endpoint, see Administrator Guide for
Scopia XT Endpoint for IP Office.
You can also perform advanced configuration from the web interface. See
Managing your XT Endpoint
from the Web Interface on page 54 for details.
Before you begin
Ensure that you have the password to access the Advanced settings. The default password is 1234.
Procedure
1. From the endpoint's main menu, select Configure > General.
Installation Guide for Scopia XT5000 Endpoint with Embedded
Server for IP Office Version 3.2
Initial Configuration | 66
