You can also switch between ABC, abc, and 123 input methods by pressing 1/a/A repeatedly
while the cursor is in the input field.
Pairing an XT Remote Control Unit with a XT Codec Unit
About this task
Multiple XT Codec Units can be set up in the conference room and controlled with different XT Remote
Control Units.
Each XT Remote Control Unit is dedicated to one XT Codec Unit by pairing them. This is done by
configuring the same numeric code in your XT Remote Control Unit and the system software.
An XT Remote Control Unit is configured with code 01 by default.
Before you begin
Decide what numeric code you want to use for your monitor and the XT Codec Unit. You can choose
any value between 1-99.
Procedure
1. Access the general settings, as follows:
•
From the web interface, select Basic Settings > General.
•
From the endpoint's Main menu, select Configure > General.
